Easy Drain Compact 30 Flange EDCOMPR50030 shower drain with stainless steel flange 50cm side spout
Brand:
Easy Drain Compact 30 Flange EDCOMPR50030 shower drain with stainless steel flange 50cm side spout
€258.00
incl. VAT
Brand:
stainless steel brushed
Algemeen
Series
Easy Drain Compact 30 Flens
Brand
Easy Drain
Delivery time
1 - 2 weeks
Color
stainless steel brushed
Douchegoot
Grate width
50mm
Installation depth
70mm - 79mm
Grate length
500mm
Max drainage capacity
32 l/min
Grate look
pattern with holes
Installation option
Floor drain with flange
Outlet
Horizontal outlet
Pre-assembled sealing membrane
No
Outer tube diameter
40mm
Showerdrain one-pack
- Yes
- standard with grid
Specifications
Location in a shower
Free in the floor, Between two walls, One-sided, Three-fold
Characteristics
Adjustable grate, Wheelchair accessible
Max drainage capacity entrance
25 l/min
Floor type
Sand cement, Concrete
Water seal height
30mm
Siphon
Cleanable drainage siphon
Description
Easy Drain Compact 30 Flange shower drain
Ideal for the tiler
With Easy Drain Compact you opt for the shallowest shower drain in the world, the solution for renovation. The all-round metal flange is ideal for the tiler. This makes the shower drain even easier to handle. Furthermore, the Compact has an easy to clean siphon with very high drainage capacity.
Grid - Standard
Built-in part - Water lock 30 mm
Product advantages
- Installation depth - 73 mm
- Application - renovation
- Finishing part - adjustable in height
- Siphon - removable and cleanable
Characteristics - Adjustable grid, Sound-absorbing, Suitable for wheelchair   Â
